Powerplant |
|
|
Engine
|
Ford Zetec-E 2.0 DOHC 16v (Series 3
'blacktop'), cast iron block, alloy head |
|
|
Supplied as a brand
new crated engine from Power Torque Engineering Ltd, Coventry in 2012 |
|
|
Standard
Zetec 1.8 flywheel & clutch |
|
|
Mitsubushi
alternator (Bedford Rascal) |
|
|
Standard sump |
|
Fuelling |
Suzuki GSXR 750 throttle bodies
respaced to Zetec bore spacing |
|
|
Keihin
270cc/min fuel injectors
(from GSXR 750 installation) |
|
|
Bosch fuel injection pump |
|
|
Bosch 2.5bar fuel pressure
regulator |
|
|
Front mounted 25 litre aluminium fuel tank |
|
Ignition |
Emerald K3 ECU with tunnel mounted serial port for laptop interface |
|
Exhaust |
Sylva custom stainless 4-1 with wideband lamda
sensor
& Innovate LM-1 controller |
|
Max
Power |
Approx 165bhp |
|
Power to
weight |
Approx 300bhp/tonne (unladen),
235bhp/tonne (2 up) |
|
|
Transmission |
|
|
Gearbox |
Ford Ka 5-speed (Endura
engine spec) |
|
|
Fiesta
lever with unique
rose jointed rod linkage |
|
Clutch |
Standard 220mm Zetec
clutch plate, hydraulic operation via standard Ka master & slave
cylinders |
|
Driveshafts |
Mk2 Fiesta XR2 |
|
|
Wheels |
15"x6.5"
Inovit Rapid 16 spoke, gloss black finish, machined highlight |
|
|
Tyres |
195/50 R15 Toyo T1R |
|
|
Chassis |
Steel
spaceframe skinned with bonded and rivetted aluminium panels
|
|
|
Body |
7-piece hand layup clear gel coat fibreglass body (main
tub, bonnet, engine cover, 2x cycle wings, 2x rear wings) sprayed with BMW 'Hella Red' paint |
|
|
Suspension |
|
|
Front |
Double wishbone |
|
|
Sierra front uprights |
|
|
Pro-tech alloy-bodied coil-over dampers with
275lb/in springs |
|
Rear |
Double wishbone |
|
|
Modified Fiesta Mk2 XR2 front uprights |
|
|
Pro-tech alloy-bodied coil-over dampers
with 275lb/in springs |
|
|
Custom rose jointed aluminium toe links |
|
|
Steering |
Escort Mk2 rack (modified by Sylva for reduced travel) |
|
|
Sierra upper steering column |
|
|
Sylva fabricated Sierra - Montego hybrid lower column |
|
|
Mountney M-range steering wheel with collapsible
boss |
|
|
Brakes |
|
|
|
Twin Girling master cylinders, bias bar |
|
Front |
Sierra callipers |
|
|
Sierra ventilated 240mm disks |
|
Rear |
Sierra callipers |
|
|
Mk2 Fiesta 1.3 solid front disks |
|
|
Weight |
544kg with all fluids
and full tank of fuel (needs re-measuring after 2012 engine/gearbox
upgrade) |
|
|
40% front : 60% rear |
|
|
Radiator |
VW Polo 1.0 (380 x 330 core), S-V-C fan |
|
|
Pedals |
Sylva modified Montego pedals incorporating bias bar tube |
|
|
Electrical |
Handbuilt loom |
|
|
Dash-mounted battery cut-off switch |
|
|
Front mounted Mini battery |
|
|
Instrumentation
|
Greengauges instruments (Speedo, tacho,
water temperature, oil pressure, fuel level) |
|
|
'Hyper-brite' LED shift light
|
|
|
Interior |
Sylva moulded dash panel finished with wrinkle
effect paint |
|
|
Fiat 126 heater matrix with 4
dashboard-mounted eyeball vents |
|
|
Sylva seats & headrests (made by Intatrim) |
|
|
Wiper
|
Mk2 Fiat Uno |
|
|
Metro washer reservoir |
|
|
Washer jet mounted to
bonnet
|
|
|
